Verifying the PID mode and connecting to the fabric
To verify PID mode, connect the system to the fabric and verify status, follow these
steps:
1. Before connecting the SAN384B to the fabric, verify that the port identifier
(PID) mode on the SAN384B matches the other switches in the fabric. This
parameter must be set identically on all switches in the fabric. This parameter
is set using the configure command. For information on PID mode, refer to the
Fabric OS Administrator's Guide.
2. Verify the chassis and port status by entering the switchShow command. This
command provides detailed information about the SAN384B.
3. Verify fabric connectivity by entering the fabricShow command. This command
provides general information about the fabric.
Software licenses
Certain licenses may be factory installed on the SAN384B. To determine which
licenses are currently enabled, use the licenseShow command.
swDir:admin> licenseshow
AAbbccDDeeFFeeGG:
Web license
Zoning license
Extended Fabric license
Fabric Watch license
Performance Monitor license
Trunking license
Security license
In the example above, the license key is AAbbccDDeeFFeeGG. Keep a copy of the
license key for reference.
The 64-bit chassis ID is required to obtain and activate licenses for the SAN384B.
The chassis ID is available through the licenseIdShow command.
The licenseShow and licenseIdShow commands must be entered on the active CP
blade.
Refer to the Fabric OS Administrator's Guide for more information.
Installing transceivers and attaching cables
Follow these steps to install SFPs, SFP+s, mSFPs (FC8-64 port blade only), or XFPs
(FC10-6 port blade only) and cables to the blades and chassis.
Note: For a listing of transceivers compatible with this product:
v Go to the IBM SAN web page www.ibm.com/systems/storage/san
v Select the SAN384B product link
v On the SAN384B product page, click the Interoperability Matrix link.
v In the Interoperability matrix, click the Transceivers link.
Attention: mSFP transceivers are compatible only with the FC8-64 port blade.
While they will fit in other blades, this configuration is unsupported and will
generate an error.
Chapter 3. Starting and configuring the SAN384B 41
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
