Chapter 2. Installing a SAN384B in a cabinet
The SAN384B is only available for installation in the IBM TotalStorage
®
2109 SAN
Switch Cabinet C36. This product is to be installed and serviced only by qualified
IBM service representatives. The SAN384B can be ordered pre-installed in the
cabinet, or it can be added to an existing C36 cabinet. The cabinet is designed to
support a total of three SAN384Bs. Each installation of the SAN384B requires the
port-side exhaust vent kit, which directs the exhaust to the service aisle and also
serves as the rack installation kit. If three SAN384B products are ordered, two will
be pre-installed in the C36 cabinet, and the third will be installed in the cabinet at
the customer site.
This chapter describes how to install a SAN384B into a C36 cabinet, and how to
remove the SAN384B from the cabinet in the event you need to move or replace
the SAN384B. If all SAN384B units are already installed in the cabinet, continue on
to Chapter 3, “Starting and configuring the SAN384B,” on page 33. The installation
requires a minimum of two people for a safe installation.
Attention: Refer to “Safety notices” on page xiii for general safety instructions
“Safety notices and labels” on page xiii, and “Rack safety” on page xix before
performing any installation or service procedures.
svc00169
55 kg ( 121.2 lbs)
CAUTION:
The weight of this part or unit is more than 55 kg (121.2 lb). It
takes specially trained persons with a lifting device to safely lift
this part or unit. (C011)
CAUTION:
A fully populated SAN384B weighs approximately 68 kg (150 lb). Before you
install it, verify that the additional weight of the chassis does not exceed the
cabinet's weight limit or unbalance the cabinet. When you calculate the
additional weight, include the weights of all components that can potentially be
added, to avoid overloading in the future.
CAUTION:
For CA residents only: IBM recommends installing this product in a room size
of 62 cubic meters (2190 cubic feet) or larger at 0.4 ACH ventilation rate to
reduce the concentrations of any chemicals emitted by the product.
Ordering the lift tool
Important
The lift tool is required only when you install an additional SAN384B or
when you install or remove the SAN384B from the cabinet. Ensure that the
lift tool will be available on location at the time of the installation.
The ordering procedures for the lift tool vary depending on your location. You
should direct questions about these procedures to your regional representative.
© Copyright IBM Corp. 2009, 2010 11
