1 Status LED 5 FC ports 0-5 (numbered right to left)
2 Power LED 6 FC ports 6-11 (numbered right to left)
3 1 GbE ports 0-3 (numbered right to left) 7 1 GbE ports 4-9 (numbered right to left)
4 10 GbE ports 0-1 (numbered right to left)
1 Status LED 3 10 GbE FCoE ports 0-11 (numbered right to left)
2 Power LED 4 10 GbE FCoE ports 12-23 (numbered right to left)
3
4
5
6
7
1
2
384b067
Figure 57. FX8-24 extension blade
3
4
1
2
384b068
Figure 58. FCOE10-24 blade
Appendix D. Blade port numbering 139
|
|
|
|
|
|
|
|
|
||||
||||
||||
||||
|
|
||||
||||
|
