5. Open the terminal emulator application and configure as follows:
v In a Windows environment:
Table 8. Configuration parameters
Parameter Value
Bits per second 9600
Data bits 8
Parity None
Stop bits 1
Flow control None
v In a UNIX
®
environment, enter the string at the prompt:
term /dev/ttyb -9600
If ttyb is already in use, use ttya instead and enter the following string at the
prompt:
term /dev/ttya -9600
Logging in to the serial console port
To log in to the SAN384B through the serial connection, follow these steps.
1. When the terminal emulator application stops reporting information, press
Enter. You will receive the following login prompt: CP0 Console Login:
2. Log in to the SAN384B as admin. The default password is "password." At the
initial login, you are prompted to change the default passwords. Record the
new passwords and keep this information in a secure location. The example
below shows the login without changing the password.
swDir login: admin
Password:
Please change your passwords now.
Use Control-C to exit or press 'Enter' key to proceed.
Password was not changed. Will prompt again at next login
until password is changed.
swDir:admin>
3. (Optional) Modify passwords. To skip modifying the password, press Ctrl+C
.Passwords can be 8 to 40 characters long. They must begin with an alphabetic
character. They can include numeric characters, the dot (.), and the underscore
(_). Passwords are case-sensitive, and they are not displayed when you enter
them on the command line. For more information on passwords, refer to the
Fabric OS Administrator’s Guide.
Configuring the IP addresses
The SAN384B requires three IP addresses, which are configured using the
ipAddrSet command. IP addresses are required for both CP blades (CP0 and CP1)
and for the single logical switch (shown as SWITCH under the ipAddrShow
command) in the
Note: The default IP addresses and host names for the SAN384B are as follows:
v 10.77.77.75 for CP0 (the CP blade in slot 4 at the time of configuration)
v 10.77.77.74 for CP1 (the CP blade in slot 5 at the time of configuration)
36 SAN384B Installation, Service, and User Guide
