10. Attach the lift tool retention straps to secure the chassis to the load plate. This
is particularly important if you will be moving the chassis across any uneven
floor, or will be raising the chassis more than 45 cm (18 inches).
11. For safety considerations during moving, lower the load platform to its lowest
position.
12. Release the lift tool brake, and carefully move the chassis near the cabinet for
installation.
Installing the port-side exhaust kit
Complete the following instructions to install the port-side exhaust kit in a
2109-C36 cabinet before installing the SAN384B chassis.
Exhaust kit parts list
Table 5 lists items illustrated in Figure 6 on page 19.
Table 5. Parts list for port-side exhaust kit for C36 cabinets
Item Description Quantity
A Top rail 1
B Duct 1
C Shelf 1
D 10-32 x .5 in. (1.27 cm)
Phillips screw (blue Loctite
on threads)
12
E 10-32 x .63 in.(1.60 cm)
Phillips screw with square
cone washer
12
F 10-32 clip nut for cabinets
that have rails with round
holes
8
G 10-32 retainer nut for
cabinets that have rails with
square holes
8
H Alignment washer for
cabinets that have rails with
square holes
12
I 6-32 x .25 in. (.635 cm)
Phillips screw
2
18 SAN384B Installation, Service, and User Guide
