Table 2. Blades available for the SAN384B (continued)
Description Feature Code Name Function
64-port 8-Gbps port
blade
FC3864 FC8-64 A 64-port port blade
supporting 2, 4, and
8 Gbps port speeds.
This blade cannot be
used in the same
chassis with an
FCOE10-24 blade.
6-port 10-Gbps port
blade
FC3870 FC10-6 A 6-port blade
supporting 10-Gbps
port speed. Blade
provides 10-Gbps
ISLs.
Fibre Channel router
blade
FC3850 FR4-18i The FR4-18i blade
has 16 4-Gbps
physical Fibre
Channel SFP ports
supporting Fibre
Channel Routing
Services and two
physical Gigabit
Ethernet (GbE) SFP
ports supporting
Fibre Channel Over
IP (FCIP). The two
physical GbE ports
can support up to 16
virtual E_ports.
FCIP extension blade FC3890 FX8-24 The FX8-24 blade
enables FCIP
functionality over
existing IP
infrastructure. It has
twelve FC ports, ten
1 GbE ports, and two
10 GbE ports
available.
Fibre Channel over
Ethernet blade
FC3880 FCOE10-24 The FCOE10-24 blade
enables FCoE
functionality over
existing Ethernet
infrastructure
utilizing CEE
protocols. It has
twenty-four 10 GbE
ports available. This
blade cannot be used
in the same chassis
with an FC8-64 high
density port blade or
the FR4-18i or FX8-24
application blades.
6 SAN384B Installation, Service, and User Guide
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
