d. Tighten the four 6-32 screws on the top of the shelf, which were loosened
to adjust the shelf length.
5. Install the air-duct assembly (B in Figure 6 on page 19) by inserting it down
into the side slot on left side of the shelf (see Figure 9). Ensure that the tabs of
the duct align and engage with the slots in the shelf, with the open side of the
duct facing towards the center of the cabinet.
6. Attach the top-rail assembly (A in Figure 6 on page 19) to the air-duct assembly.
a. The top-rail assembly can be adjusted to a length of between 27 and 31
inches (68.58 to 78.74 cm) to fit on the inside of the cabinet rails. To lengthen
or shorten the top-rail assembly, loosen, by approximately 1/2 turn, the two
Port Side
(Exhaust)
384b034
Figure 8. Shelf installed in cabinet
384b036
Figure 9. Air duct installed into side slot in shelf
22 SAN384B Installation, Service, and User Guide
