Table 21. System architecture (continued)
Port types FC8-16 and FC8-32 support these port types:
FL_Port, F_Port, E_Port, and M_Port
FC8-48 supports these port types:
E_Port, F_Port, and M_Port
FC8-64 supports these port types:
F_Port, FL_Port, E_Port, Ex_Port, and M_Port
FC10-6 supports these port types:
E_Port and M_Port
FR4-18i supports these port types:
FL_Port, F_Port, E_Ports, M_Port, VE_Port, EX_Port, and
VEX_Port
FX8-24 supports these port types:
F_Port, FL_Port, E_Port, and Ex_Port on FC
VE_Port on GbE
FCOE10-24 supports these port types:
VF_Port
Note: Self-discovery is based on switch type (U_Port)
with an optional port type control.
Data traffic types Fabric switches supporting unicast, multicast (255
groups), and broadcast
Media types Note: Brocade-branded SFPs are required on this
product.For a listing of SFPs and XFPs compatible with
this product:
v Go to the IBM SAN web page http://www.ibm.com/
systems/storage/san
v Select the SAN384B product link
v On the SAN384B product page, click the
Interoperability Matrix link.
v In the Interoperability matrix, click the Transceivers
link.
Fabric services Access Control Lists (ACLs); Advanced Performance
Monitoring; Adaptive Networking (Ingress Rate
Limiting, Traffic Isolation, QoS); auditing; BB credit
recovery; Brocade Advanced Zoning (default zoning,
port/WWN zoning, broadcast zoning); Dynamic Path
Selection (DPS); End-to-End Performance monitoring;
Extended Fabrics; Fabric Watch; FDMI; FICON CUP;
Frame Redirection; FSPF; Integrated Routing (FR4-18i
SAN Extension blade not required for routing); IPFC; ISL
Trunking; Management Server; N_Port Trunking; NPIV;
NTP v3; Port Fencing; RASlog; Registered State Change
Notification (RSCN); Reliable Commit Service (RCS);
Simple Name Server (SNS); syslog; Top Talkers; Virtual
Fabrics (Logical Switch, Logical Fabric); Web Tools
Inter-chassis linking (ICL) Chassis-to-chassis linkage through connectors on the core
switch blade (CR4S-8)
Appendix A. Product specifications 121
|
|
