TASCAM HS-4000 89
12 – Other functions
Online functions
Use the ONLINE key to turn this function on/off.
Enabling the online function
In order to use online function, the online function must be set
to Switchable.
1. Press the MENU key on the front panel to open the
MENU screen.
2. Press the
SYSTEM SETUP button to open the SYSTEM
SETUP
screen.
3. Touch the
Switchable button of the ONLINE
Function
item to change the online function setting
(default value:
Switchable).
When the online function setting is
AlwaysON, the online
playback mode is always enabled and the ONLINE key stays
lit to indicate this status.
Switching the online playback mode
When the online function can be changed (ONLINE Function
item is set to Switchable), the following operations can be
used to turn the online playback mode on/off.
HS-4000 front panel: Press the ONLINE key
When connected to a parallel control: ONLINE event
When connected to an RS–232C serial control: ONLINE
command
TASCAM RC–HS32PD remote controller (sold separately):
press the ONLINE key
In dual mode, only online playback mode for the selected player
can be turned ON/OFF on screen. When using a TASCAM
RC–HS32PD remote controller (sold separately), however,
regardless of which player is selected, you can press the player A
or B ONLINE key to turn online playback mode ON/OFF for the
orresponding player. c
When online playback mode is turned ON/OFF, the following
occurs depending on the mode.
Timeline, take and single playlist modes
When online playback mode is turned ON, the Home Screen
opens automatically, and the
icon appears red at
the top of the screen.
When online playback mode is turned OFF, the
icon does not appear at the top of the screen.
Dual playlist mode
When online playback mode is turned ON, the Home Screen
opens automatically, and the
icon appears partially red at
the top of the screen.
When online playback mode is turned OFF, the
icon at the
top of the screen becomes
.
Outputs during online playback
The relationship between online playback mode and sound
outputs are as follows.
Online playback mode OFF ON
Analog line outputs (1−4) – O
Digital line outputs (1−2, AES/EBU) – O
Analog monitoring outputs (L, R) O* O*
Headphones O* O*
RC–HS32PD (headphones, speakers) O* O*
*The monitoring signal is always output.
CAUTION
When the ONLINE Function item is set to AlwaysON, sound is always output
from all connectors.
CAUTION
By turning the Monitor Mute by Online item (MIXER SETUP screen
SETUP page) ON, you can enable monitoring output to automatically be
turned off when online playback mode is on. (For details about the
Monitor
Mute by Online
item, see “SETUP page” of “Mixer settings (MIXER SETUP)” in
10 – Internal settings.)
