52 TASCAM HS-4000
8 – Take mode
Playback
Project/session/take selection
1. Press the PROJECT key on the front panel to open the
PROJECT screen.
NOTE
You can also touch the session/take name area on the Home Screen to open
the
PROJECT screen.
2. Touch the e button for the project that contains the
take you want to load to open the session selection
screen. If it is not the current project, a pop-up
window appears confirming that you want to load it.
Touch the
OK button.
3. Touch the e button for the session that contains the
take you want to load to open the take selection
screen. If it is not the current session, a pop-up
window appears confirming that you want to load it.
Touch the
OK button.
NOTE
To load a take from the current session, instead of steps 1–4 above, touch the
session name button at the top right of the project screen or touch the take
name button on the Home Screen, and touch the
TAKE List button in the
pull-down menu to open the take selection screen for the current session.
4. Select the take that you want to load.
5. Touch the
MENU button in the take selection screen to
open the pull-up menu.
6. Touch the
LOAD button in the pull-up menu.
7. When a confirmation message appears in the pop-up
window, touch the
OK button or press the DATA dial.
When loading completes, the Home Screen opens.
NOTE
You can also press the e button for a take to load it.
In this case, no pop-up window appears, and the take selection screen
remains open after loading (the Home screen does not reopen.)
Setting input monitoring
Turn input monitoring OFF for the channels (tracks) to be played
back. When input monitoring is ON for a channel, sound will be
input through that channel’s audio input.
1. Touch the
REC/MON button on the Home Screen to open
a pull-up with
REC and MON buttons.
2. If input monitoring is on for any playback channels (
MON
buttons appear blue), touch those
MON buttons to turn
them off (turning them gray).
Setting the online function
Refer to “Online functions” on page 89 for details about making
settings for the online outputs.
Playback control
Press the PLAY key to start playback.
Press the PAUSE key to pause playback.
Press the PLAY key again to resume playback.
Press the STOP (RETAKE) key to stop playback.
Press the. [MARK.] key or / [MARK/] key to
switch takes.
Press and hold the m [
] or , [ ] key to search
backward or forward.
