TASCAM HS-4000 29
4 – Basic operation
Setting inputs and outputs
Setting the inputs
1. Press the MENU key on the front panel to open the
MENU screen.
2. Touch the
MIXER SETUP button to open the MIXER
SETUP
screen.
On the INPUT page, make settings for each channel’s input
source. For details, see “INPUT page” on page 78.
3. If necessary, touch the MONITOR MIXER or SETUP tab
to open the corresponding page where various
settings can be made.
On the MONITOR MIXER page, make settings related to the
internal monitoring mixer. For details about this screen, see
“MONITOR MIXER page” on page 78.
On the
SETUP page, you can turn the muting function for
monitoring during online playback on/off.
Setting reference levels
1. Press the MENU key on the front panel to open the
MENU screen.
2. Press the
SYSTEM SETUP button to open the SYSTEM
SETUP
screen.
On the PREFERENCES page, set the digital reference level,
analog input reference level and analog output reference
level. (You can also set the keyboard type and online
function on this page.)
For details, see “PREFERENCES page” on page 80.
3. If necessary, touch the
ANALOG Ref. LEVEL ADJUST
tab to adjust each channel.
On the ANALOG Ref. LEVEL ADJUST page, you can make
precise adjustments to the reference levels of the analog
inputs and outputs for each channel independently. For
details about this screen, see “ANALOG Ref. LEVEL ADJUST
page” on page 80.
NOTE
On the CLOCK ADJUST page, you can change the system time.
