62 TASCAM HS-4000
9 – Playlist mode
NOTE
The display of the buttons differs somewhat according to whether the player
mode is set to single or dual mode and whether the
RC–HS32PD Flash
Start Key Mode
item is set to 16X2 or 12X2. (For more about the
RC–HS32PD Flash Start Key Mode item, see “Setting the flash key
function” on page 90.)
4. Use the “+” and “–” buttons to open the page where
you want to assign a file.
5. In single mode, select
1–16 or 17–32 to show the
flash start key to which you want to assign a file.
Single
mode 1–16
Single mode 17–32
When in dual mode touch the A:1–16 button to make an
assignment for player A, or touch the
B:1–16 button to
make an assignment for player B.
Dual mode player A
Dual mode player B
6. In the key assign button list on the left, select the one
that you want to assign to. The selected button appears
light blue.
NOTE
If you select a button that already has an entry assigned to it, the
corresponding take appears like yellow in the take list.
7. Touch a take name in the take list to assign that take
to that button.
When a take is assigned to a button, the button’s icon
changes from (no assignment) to .
NOTE
Only takes in the project where the playlist is can be added to the playlist.
If the take that you want to add does not appear, use the scroll buttons or
DATA dial to scroll through the list until the take appears and then touch
its name.
TIP
If the take that you want to add is in a different session in the same project,
touch the current session name button to open the session list. Then, touch
the name of the session that contains the take that you want to add to open
that session’s take name list.
8. Repeat steps 3–7 as necessary.
9. After you have completed making assignments, save
the playlist as necessary.
To save a playlist, touch the
MENU button on the ASSIGN file
or ENTRY list screen to open a pull-up menu, and touch the
SAVE button (in dual mode, SAVE A+B button). From the
Home Screen, you can touch a file name or title name
button to open a pull-down menu with the
SAVE button (in
dual mode,
SAVE A+B button). For details about saving, see
“Saving a playlist” on page 67.
CAUTION
If you do not save the playlist, all changes will be lost when another playlist is
loaded, the CF card is removed or the unit’s power is turned off, for example.
Entry number page allocation
P
laylist entry numbers are displayed according to the player mode and key mode settings.
Mode Single mode Dual mode
RC-HS32PD Flash Start
Key Mode setting
16x2 16x2 12x2
Key set selection button 1-16 17-32 A1-16 B1-16 A1-12 B1-12
1
2
3
4
5
6
7
Page
number
8
Note: “―” means there is no corresponding page.
A:” indicates entry numbers for the Player A playlist, and “B:” for the Player B playlist.
