72 TASCAM HS-4000
10 – Internal settings
CAUTION
・ In both modes, a subfolder is created for each take inside the folder, and
management files are generated in these subfolders.
・ When Session Root mode is selected, the maximum number of takes
that can be recorded in a single session is greatly reduced from normal.
For this reason, when switching to Session Root mode the following
pop-up window appears with a warning about the reduced maximum
limit to the number of takes.
When switching to Sub Folder mode, the following pop-up window
appears explaining the restored maximum limit to the number of takes.
・ When Session Root mode is selected, the number of files created is large.
For this reason, the maximum number of takes that can be recorded is
greatly reduced. (See “Recording operation limitations” on page 30.)
・ During recording, you can press the REC key to start recording a new
take. This function can be used 4 seconds after beginning recording in
polyphonic and subfolder modes, but inSession Root mode, you might
have to wait more than 4 seconds.
Bit Length
Set the quantization bit rate for recording files using the
following buttons.
Setting buttons:
16bit (default), 24bit
Max File Size
Set the maximum size for recording files using the following
buttons.
Setting buttons:
640MB, 1GB, 2GB (default)
Pause Mode
Set whether or not to divide files when a recording is paused
using the following buttons.
Setting buttons:
SPLIT (default), NO SPLIT
OPTIONS page
Make settings related to the pre–recording and auto markers.
PreREC Time
When PreREC Time is ON, the signal input during recording
standby is captured by the built-in memory for the set amount of
time, allowing a maximum of 5 seconds to be recorded before
recording is started manually.
To set the pre–recording time, touch the knob, and adjust the
value using the DATA dial.
Setting range: 1–5 seconds (default:
2 seconds)
Auto Marker
Make settings related to auto markers.
Audio Over:
Use this to add markers when the set audio level is
exceeded.
Turn this function ON or OFF and set the detection level.
(Default:
OFF)
To set the detection level, touch the knob, and adjust the
value using the DATA dial.
Setting options:
–0.20dB (default), –0.17dB, –0.13dB,
–0.10dB, –0.06dB, –0.03dB
Settings made here are reflected in the Over Level setting
on the
METER SETUP screen.
Time Interval:
Use this to add marks at fixed time intervals. Turn this
function ON or OFF and set the time interval. (Default:
OFF)
To set the time, touch the knob, and adjust the value using
the DATA dial. The range of setting values is 1–10 minutes
(default:
5 minutes).
Sync Unlock:
Use this to add a mark when synchronization with the
master clock is lost. Turn this function ON or OFF. (Default:
OFF)
NOTE
An “audio over” occurs when the level exceeds the maximum level (full scale)
minus the value set by the user. (In the example above, this would be when
the level exceeds the maximum level minus 0.20 dB.)
