TASCAM HS-4000 79
10 – Internal settings
SETUP page
Monitor Mute by Online
Set whether monitoring is automatically muted or not during
online playback (default:
OFF).
Output 1-4 Source
Select the output signals for Outputs 1-4.
CH1-4 OUT button (default):
Output the signals of CH1-4 as is to the ANALOG LINE OUT
1-4 connectors.
1+3/2+4 Mix Out button:
The signals of CH1 and CH3 are mixed and output through
the ANALOG LINE OUT 1 and 3 connectors and the left
channels of the DIGITAL LINE OUT 1 and 2 connectors, and
the signals of CH2 and CH4 are mixed and output through
the ANALOG LINE OUT 2 and 4 connectors and the right
channels of the DIGITAL LINE OUT 1 and 2 connectors.
NOTE
A and B indicate Players A and B, and + indicates that the signals are mixed.
Level meters settings (METER SETUP)
Make level meter settings on this screen.
Metering Point
Set whether the meters show the signal before or after the
online faders.
:
Meters show the signal before the faders
(default).
:
Meters show the signal after the faders. In this
case, the button appears light blue.
Ref. Level Line
Touch to turn the reference level line that appears on the level
meter
ON (default) or OFF.
Reference level line display ON
Over Level
Use this to set the level at which the overload indicator lights.
The peak indication level is this amount below the maximum
level (full scale).
Touch this knob and use the DATA dial to adjust the level.
Options:
–0.20 dB (default), –0.17 dB, –0.13 dB, –0.10 dB,
–0.06 dB, –0.03 dB.
This setting is reflected in the Audio Over setting of the Auto
Marker item on the OPTIONS page of the REC SETUP screen.
Peak Hold Time
Use this to set the peak hold time.
Touch this knob and use the DATA dial to adjust the time.
Options:
0 sec, 1 sec, 2 sec (default) and inf (hold forever).
Release Time
Use this to set the release time.
Touch this knob and use the DATA dial to adjust the time.
Options:
Slow, Normal (default) and Fast
NOTE
If you press the EXIT/CANCEL (PEAK CLEAR) key when the Home Screen is
open, the peak hold display resets.
