MEASUREMENT & INSPECTION
MEASURING LIGHT
SCREENS
TEMPERATURE
ULTRASONIC
LIGHT
GAUGING
RADAR
R-GAGE
™
QT50R
Radar-Based
Adjustable-Field Sensor
For close and long-range presence detection in
extreme weather conditions
The R-GAGE™ QT50R uses Frequency Modulated Continuous
Wave (FMCW) radar to reliably detect moving or stationary
targets, including cars, trains, trucks and cargo. Immune to most
weather conditions, the QT50R effectively resists rain, wind,
humidity and temperature.
• Providespresence,absenceorchangeinformationfor
a detected target
• Detectsobjectsuptoasetdistance,ignoringobjects
and backgrounds beyond the setpoint
• Operatesat24GHzintheIndustrial,ScientificandMedical
(ISM) telecommunication band; no special licensing required
• Withstandsextremetemperaturesandstrongwind
• Detectsvehiclesatdistancesupto15m
• IncludesDIPswitchesforsensingdistance,sensitivityand
output configuration
• Provides12to30VdcoperationwithbipolarPNP
(sourcing) and NPN (sinking) output
• FeaturesbrightLEDindicatorsforeasystatusmonitoring
Robust operation in a simple-to-use,
easy-to-configure package
• RuggedIP67housingforharshenvironments
• Integralmountingholes,30mmmountingbaseor
 optionalmountingbracketsforinstallationexibility
• 2mattachedcableor5-pinEuro-stylequick-disconnect
• Operatingtemperaturerangeof-40°to+65°C
• 8DIPswitchesforsensingdistance,sensitivityand
output configuration
- Adjustable sensing
  distanceupto15m
- Adjustable beam width
for fine-tuning sensitivity
- Selectable normally
open (NO) or normally
closed (NC) operation
- Configurable response
  speedfrom0.1to1.3seconds
Presence sensing in a broad range
of weather conditions
• Cargodetectiononatruckbed
• Truckdetectionatloadingdock
• Accesscontroltoparkingrampsandgaragedoors
• Cardetectionindrive-thru
• Positionsensingofcranes
• Cardetectionandcountingintollbooths
• Trainandtramdetectionandlocationintunnels
Yellow/Red
(Configuration)
Yellow/Red
(Output energized)
Green
(Power ON)
Red
(Flashes in proportion
to the signal strength)
QD CABLES
PAGE 415
5-Pin Euro
BRACKETS
Integral
mounting holes
Dip switch
30 mm threaded
mounting base
Attached cable
or intergal
Euro-style QD
Bright LED indicators
PAGE 373
