Unique staggered LED array allows for
industry’s tightest sensing tolerance.
PAGE 421
PAGE 373
PAGE
436
PAGE
439
5-Pin Mini
A-GAGE
®
High-Resolution
MINI-ARRAY
®
High-Resolution Inspection
and Proling Light Screen
The A-GAGE
®
High-Resolution MINI-ARRAY
®
has 120 sensing beams per foot, for reliable detection of
objects as small as 2.5 mm. It features a 2 m range with
easy, forgiving alignment and a unique TEACH setup
routine that equalizes the gain of each sensing channel to
the optimum level and automatically blanks any blocked
areas along the length of the light screen.
Ultra-precise monitoring & inspection
High-Resolution MINI-ARRAY systems excel in high-speed,
precise monitoring and inspection applications, including
on-the-fly sizing, profiling, precision edge and center
guiding, and hole detection. Setup software allows system
configuration using a PC.
• Delivers reliable 2.5 mm minimum detection
throughout the array
• Available with discrete or analog outputs
• Offers programmable blanking, hysteresis and
serial communication
• Reliably detects variable object size at a high
resolution and fast response speed
A choice of 12 array heights to fit your
precision measurement applications
• Available in heights from 163 to 1951 mm
• Features 7 measurement modes and 3 scanning methods
Many options, yet easy to program
• Software included with the control module
makes it easy to configure the many options
with a PC-compatible computer.
• Storable scanning programs eliminate
reprogramming for repeated applications.
• Non-volatile memory of controller stores
alignment settings.
