MEASUREMENT & INSPECTION
TEMPERATURE
ULTRASONIC
LIGHT
GAUGING
RADAR
MEASURING LIGHT
SCREENS
EZ-ARRAY
™
page 288
• Applications include edge and center-guiding, loop
tension control, hole sizing, parts counting and
on-the-fly product sizing and profiling.
• Closely spaced infrared beams detect objects as small
as 5 mm wide; edge resolution is 2.5 mm.
• Controller functionality is built into the receiver, so
basic setup requires no controller, software, or PC.
• Easy-to-use software is included for advanced
configuration, using a PC.
• Configuration options include 14 measurement modes,
three scanning methods, two analog and two discrete
outputs and a serial output.
• Range is 4 meters.
• Array heights range from 150 to 2400 mm.
A-GAGE
®
Measuring Light Screens
High-Resolution
MINI-ARRAY
®
page 291
• High-resolution array excels at high-
speed, precise process monitoring and
inspection applications.
• Available heights range from
163 to 1951 mm.
• Closely spaced beams detect objects as
small as 2.5 mm.
• Emitters and receivers can be
up to 1.8 m apart.
• Controllers can be configured for a
variety of measurement modes, scan
modes and output configurations.
MINI-ARRAY
®
page 296
• Low-profile light screen pairs are
designed for profiling and inspections.
• Available heights range from 133 to
1819 mm.
• Depending on the model’s beam
spacing, the array detects objects as
small as 19 to 38 mm.
• Emitters and receivers can be up to
6 m apart or up to 17 m apart,
depending on model.
• Configuration options include blanking,
sensitivity and scanning mode.
• Controllers are available with
DeviceNet
™
Compatibity output.
DeviceNet™ is a trademark of open DeviceNet Vendor Association, Inc.
