Q50 Analog Output Specifications
Sensing Beam
Wavelength: Q50..V: 685 nm (typical) Q50..: 880 nm (typical)
Beam Size: Q50..V: 20 mm dia. (max.) Q50..: 20 mm dia. (max.)
Sensing Range
Q50AV: 50 to 150 mm Q50A: 50 to 200 mm
Q50BV: 100 to 300 mm Q50B: 100 to 400 mm
Supply Voltage and Current
15 to 30V dc (10% max. ripple); 70 mA max. (exclusive of load)
Supply Protection Circuitry
Protected against reverse polarity and transient overvoltages
Output Configuration
4-20 mA current sourcing models: 1 kΩ max. load @ 24V dc. Max. load = [(Vcc -4.5)/0.02]Ω
0-10V voltage sourcing models: 15 mA max.
Delay at Power-up
2 seconds
Output Protection
Protected against short circuit conditions
Output Response Time
Analog Output Average Interval Update Rate -3 dB Frequency Response
Fast: 4 milliseconds 1 millisecond 112 Hz
Slow: 64 milliseconds 4 milliseconds 7 Hz
Resolution
See RRC-5 and RRC-6 on page 510 for typical value.
Q50B models:
Target Distance: 200 mm Slow Response: 1 mm (max) Fast Response: 4 mm (max)
Q50A models:
Target Distance: 100 mm Slow Response: 0.5 mm (max) Fast Response: 2 mm (max)
Linearity
Q50B.. models: ±3 mm Q50A.. models: ±1.5 mm
Color Sensitivity (typical)
See charts CSC-4 and CSC-5 on page 511.
Temperature Effect
Q50B.. models:
From 0° to 50° C: 0.25 mm/° C From -10° to 55° C: 0.35 mm/° C
Q50A.. models:
From 0° to 50° C: 0.08 mm/° C From -10° to 55° C: 0.11 mm/° C
Remote and Speed Input
Impedance
15 kΩ
Remote TEACH Input
To Teach: Connect gray wire to +5 to 30V dc
To Disable: Connect gray wire to 0 to +2V dc (or open connection)
Adjustments
Fast Speed: Connect black wire to +5 to 30V dc
Slow Speed: Connect black wire to 0 to +2V dc (or open connection)
Indicators
Range LED Green — Target is within sensing range
Indicator Red — Target is outside sensing range
(Green/Red) OFF — Sensor Power OFF
Teach/Output Yellow — Target is within taught window limits
LED Indicator OFF — Target is outside taught window limits
(Yellow/Red) Red — Sensor is in TEACH mode
Ambient Light Immunity
< 10,000 LUX
Construction
Housing: Molded ABS/Polycarbonate Hardware: M3 hardware is included. Window Lens: Acrylic
Environmental Rating
IEC IP67; NEMA 6P
Connections
2 m or 9 m 5-conductor PVC-covered attached cable, or 5-pin Euro-style quick-disconnect.
See page 416.
Operating Conditions
Temperature: -10° to +55° C Relative humidity: 90% at +50° C (non-condensing)
Vibration and
Mechanical Shock
All models meet Mil. Std. 202F requirements. Method 201A (Vibration: 10 to 60Hz max. double amplitude
0.06”, maximum acceleration 10G). Also meets IEC 947-5-2 requirements: 30G,
11 milliseconds duration, half sine wave.
Application Notes
Allow 15-minute warm-up for maximum performance
Certifications
Hookup Diagrams
MI09 (p. 534)
