U-GAGE
®
T30U, 15-24V dc
Models* Range Frequency Cable**
Discrete
Output(s)
Analog
Output
Response
Time
Data
Sheet
T30UUNA
150 mm - 1 m 228 kHz
2 m
NPN
0 to 10V dc 48 ms
57438
T30UUNAQ
5-pin Euro QD
T30UUPA
2 m
PNP
T30UUPAQ
5-pin Euro QD
T30UUNB
300 mm - 2 m
†
128 kHz
2 m
NPN
0 to 10V dc
96 ms
T30UUNBQ
5-pin Euro QD
T30UUPB
2 m
PNP
T30UUPBQ
5-pin Euro QD
* For sensors with Teflon
®
-protected face and transducer (long-range models only), add suffix -CRFV to the model number (example, T30UUNB-CRFV).
** For 9 m cable, add suffix W/30 to the 2 m model number (example, T30UUNA W/30). A model with a QD requires a mating cable (see page 415).
†
Teflon
®
-encapsulated models have a range of 300 - 1.5 m.
U-GAGE
®
T30U Specifications
Sensing Range
“A” suffix models: 150 mm min. near limit; 1 m max. far limit
“B” suffix models: 300 mm min. near limit; 2 m max. far limit
“-CRFV” models: 300 mm min. near limit; 1.5 m max. far limit
Effective Beam
See charts EBPC-8, EBPC-9, EBPC-10, EBPC-11 and EBPC-12 on page 514.
Supply Voltage
Current sourcing analog output models: 12 to 24V dc (10% max. ripple); 90 mA (exclusive of load)
Voltage sourcing analog output models: 15 to 24V dc (10% max. ripple); 90 mA (exclusive of load)
Dual-discrete output models: 12 to 24V dc (10% max. ripple); 90 mA (exclusive of load)
Ultrasonic Frequency
Short Range: 228 kHz
Long Range: 128 kHz
Supply Protection Circuitry
Protected against reverse polarity and transient voltages.
Output Protection
Protected against continuous overload and short-circuit; transient over-voltage; no false pulse on power-up.
Output Configuration
Discrete (switched) output: Solid-state switch conducts when target is sensed within sensing window;
choose NPN (current sinking) or PNP (current sourcing) models.
Analog output: Choose 0 to 10V dc sourcing or 4 to 20 mA sourcing output models;
output slope may be selected using TEACH sequence.
Output Ratings
Discrete (switched) output: 100 mA max., total–both outputs
OFF-state leakage current: less than 10 µA
ON-state saturation voltage: less than 1V at 10 mA and less than 1.5V at 100 mA
Analog Output:
Voltage sourcing: 0 to 10V dc (at 1 kΩ min. resistance)
Current sourcing: 4 to 20 mA, 1 Ω to Rmax.
Rmax = V
supply
- 7V
20 mA
Output Response Time
Discrete output: “A” suffix models: 48 milliseconds
“B” suffix models: 96 milliseconds
Analog output: “A” suffix models: 48 milliseconds average, 16-millisecond update
“B” suffix models: 96 milliseconds average, 32-millisecond update
Teflon® is a registered trademark of Dupont™
.
