LT3 Specifications
Laser Control
Connect red wire to +5 to 24V dc to enable laser beam; connect to 0 to +1.8V dc
(or open connection) to disable; when sensor is powered laser enable time is 100 millisecond delay on
enable, when sensor is powered.
Indicators
Green Power ON LED: Indicates when power is ON, overloaded output and laser status
Yellow Output LED: Indicates when discrete load output is conducting
Red Signal LED: Indicates target is within sensing range and the condition of the received light signal
Yellow Speed LED: Indicates the response speed setting
Red/Yellow TEACH LEDs: In programming mode; indicate active output(s)
Construction
Housing: ABS/polycarbonate blend
Window: Acrylic
Quick-disconnect: ABS/polycarbonate blend
Environmental Rating
IP67; NEMA 6
Connections
2 m or 9 m shielded 7-conductor (with drain) PVC-jacketed attached cable, or 8-pin Euro-style
quick-disconnect. QD cables are ordered separately. See page 416.
Operating Conditions
Temperature: 0° to +50° C Relative humidity: 90% at 50° C (non-condensing)
Application Notes
• For best accuracy, allow 30-minute warm-up before programming or operating
• Retroreective performance specications are based on use with supplied BRT-TVHG-8X10P
high-grade target. Results may vary with other retroreective target materials.
Certifications
Hookup Diagrams
Discrete/Analog Models: NPN: MI01 (p. 532) PNP: MI02 (p. 532)
Dual-Discrete Models: NPN: MI03 (p. 532) PNP: MI04 (p. 532)
(cont’d)
