MEASUREMENT & INSPECTION
TEMPERATURE
ULTRASONIC
LIGHT
GAUGING
RADAR
MEASURING LIGHT
SCREENS
A-GAGE
®
High-Resolution MINI-ARRAY
®
Sensors–2.5 mm Beam Spacing
Models* Cable**
Housing
Length
Total
Beams
Array
Length
Minimum
Object Size Range
Data
Sheet
MAHE6A
5-pin
Mini QD
233 mm 64 163 mm
2.5 mm 0.4 - 1.8 m
64118
MAHR6A
MAHE13A
396 mm 128 325 mm
MAHR13A
MAHE19A
559 mm 192 488 mm
MAHR19A
MAHE26A
721 mm 256 650 mm
MAHR26A
MAHE32A
884 mm 320 813 mm
MAHR32A
MAHE38A
1046 mm 384 975 mm
MAHR38A
MAHE45A
1212 mm 448 1138 mm
MAHR45A
MAHE51A
1374 mm 512 1300 mm
MAHR51A
MAHE58A
1537 mm 576 1463 mm
MAHR58A
MAHE64A
1700 mm 640 1626 mm
MAHR64A
MAHE70A
1862 mm 704 1788 mm
MAHR70A
MAHE77A
2025 mm 768 1951 mm
MAHR77A
* “E” and “R” in model numbers denotes “Emitter” and “Receiver” respectively. Sold separately.
•• A model with a QD requires a mating cable (see page 421).
A-GAGE
®
High-Resolution MINI-ARRAY
®
Controller Specifications
Power Requirements
16 to 30V dc @ 1.0 A (typical: 0.5 A @ 16V dc)
Inputs
Sensor input: Emitter and receiver wire in parallel to ve terminals.
Trigger (Gate) input: Optically isolated, requires 10 to 30V dc (7.5 kΩ impedance) for gate signal
Remote alignment input: Optically isolated, requires 10 to 30V dc (7.5 kΩ impedance) for alignment
sequence signal
Discrete (Switched)
Outputs
NPN outputs: Open collector NPN transistor rated at 30V dc max., 150 mA max.
PNP outputs: Open collector PNP transistor rated at 30V dc max., 150 mA max.
All discrete outputs: OFF-state leakage current: less than 10 µA @ 30V dc
ON-state saturation voltage: less than 1V @ 10 mA; less than 1.5V @ 150 mA
Serial Data Outputs
RS-232 or RS-485 interface. (Up to 15 control modules may be given unique addresses on
one RS-485 party line.)
ASCII or binary data format
9600, 19.2K or 39.4K baud rate
8 data bits, stop bit, and even, odd or no parity
More on
next page
