MEASUREMENT & INSPECTION
MEASURING LIGHT
SCREENS
TEMPERATURE
LIGHT
GAUGING
RADAR
ULTRASONIC
U-GAGE
®
T30U Sensors
T-style right-angle sensor package with
30 mm threaded mount
2 m or 9 m attached cable, or
quick-disconnect fitting
Easy-to-use push-button programming
LED indicators for Power, Signal and
both outputs
5-pin Euro-style QD cables with
shield ordered separately (see page 415)
U-GAGE
®
T30U, 12-24V dc
Models* Range Frequency Cable**
Discrete
Output(s)
Analog
Output
Response
Time
Data
Sheet
T30UINA
150 mm - 1 m 228 kHz
2 m
NPN
4 to 20
mA
48 ms
57438
T30UINAQ
5-pin Euro QD
T30UIPA
2 m
PNP
T30UIPAQ
5-pin Euro QD
T30UINB
300 mm - 2 m
†
128 kHz
2 m
NPN
4 to 20
mA
96 ms
57438
T30UINBQ
5-pin Euro QD
T30UIPB
2 m
PNP
T30UIPBQ
5-pin Euro QD
T30UDNA
150 mm - 1 m 228 kHz
2 m
Dual NPN
None 48 ms
59200
T30UDNAQ
5-pin Euro QD
T30UDPA
2 m
Dual PNP
T30UDPAQ
5-pin Euro QD
T30UDNB
300 mm - 2 m
†
128 kHz
2 m
Dual NPN
None 96 ms
59200
T30UDNBQ
5-pin Euro QD
T30UDPB
2 m
Dual PNP
T30UDPBQ
5-pin Euro QD
T30UHNA
150 mm - 1 m 228 kHz
2 m
Pump/Level
Control
Dual NPN
None
48 ms
63974
T30UHNAQ
5-pin Euro QD
T30UHNB
300 mm - 2 m
†
128 kHz
2 m
96 ms
T30UHNBQ
5-pin Euro QD
T30UHPA
150 mm - 1 m 228 kHz
2 m
Pump/Level
Control
Dual PNP
None
48 ms
63974
T30UHPAQ
5-pin Euro QD
T30UHPB
300 mm - 2 m
†
128 kHz
2 m
96 ms
T30UHPBQ
5-pin Euro QD
* For sensors with Teflon
®
-protected face and transducer (long-range models only), add suffix -CRFV to the model number (example, T30UINB-CRFV).
** For 9 m cable, add suffix W/30 to the 2 m model number (example, T30UINA W/30). A model with a QD requires a mating cable (see page 415).
†
Teflon
®
-encapsulated models have a range of 300 - 1.5 m.
Short-range Models
45.0 mm
51.5 mm
ø 40.0 mm
Long-range Models
Teflon-protected Models
Suffix -CRFV
Teflon
®
is a registered trademark of Dupont
™
