More information online at bannerengineering.com
243
MEASURING
LIGHT SCREENS
TEMPERATURE
ULTRASONIC
MEASUREMENT & INSPECTION
RADAR
LIGHT
GAUGING
L-GAGE
®
Light Gauging Sensors
LT7 page 248
• Extremely long-range sensor uses a
Class 1 laser beam for accuracy over long
distances.
• Retroreflective mode sensor has
250 m range.
• Ranges with diffuse mode sensor are up
to 10 m for white, 7 m for gray and 3 m for
black targets.
• Models are available with discrete output
only or with discrete and analog output.
• RS-422 or SSI compatible serial
connections are provided.
LT3 page 244
• Exceptionally accurate advanced time-of-flight
sensing technology provides precise measurements
over long ranges.
• Retroreflective mode sensor has 50 m range.
• Ranges with diffuse mode sensor are 5 m for white
targets and 3 m for gray targets.
• Sensors offer either analog and discrete, or
dual-discrete output, with independent window limits.
LG page 252
• One-piece laser gauging system requires
no separate controller.
• Ultra narrow beam delivers precise
distance, height and thickness
measurement and gauging.
• Two sensing ranges are available:
45 to 60 mm and 75 to 125 mm.
Q50 page 256
• LED sensor delivers laser-like performance
in a compact, low-cost package.
• Models are available to gauge distances
either from 100 to 400 mm or 50 to 200 mm,
with analog or discrete output.
• Features include high resolution and a fast,
selectable response time.
