MEASUREMENT & INSPECTION
MEASURING LIGHT
SCREENS
TEMPERATURE
LIGHT
GAUGING
RADAR
ULTRASONIC
S18U page 266
• Compact 18 mm straight or
right-angle housing
• Highly accurate detection from
30 to 300 mm
• Wide range of mounting options
U-GAGE
®
Ultrasonic Sensors
QT50U page 262
• Long-range ac or dc sensor covers 8 m, with minimal
dead zone.
• Advanced programming capability includes a unique
temperature compensation feature.
• Retrosonic mode has reduced dead zone.
• Each output has two independent near and far limits.
• Optional Teflon
®
coating resists harsh chemicals.
QS18U page 269
• Compact 18 mm universal housing
• Compensation for air temperature
fluctuations
• Optional encapsulation for
resistance to harsh chemicals
(IP68)
T30U page 272
• Right-angle T-style housing with
30 mm threaded lens
• Analog and discrete outputs in
the same sensor
• Programmable sensing windows
with 150 mm to 1 m range or
300 mm to 2 m range
• Optional Teflon
®
coating for
resistance to harsh chemicals
Q45U page 276
• Operating window limits from
100 mm to 3 m
• Discrete output models for ON/OFF
presence detection or HIGH/LOW
level control
• Programmable response time
Q45UR page 280
• Ultra-accurate remote gauging
• Compact housing with choice of
three remote sensing heads
• Compensation for temperature
variations at remote head
T18U page 284
• Dual range, opposed ultrasonic sensors
• Two combinations of range and
response time in the same unit
• Ideal for sensing under bright
lighting and for clear materials
• T-style sensor with 18 mm threaded lens
Teflon
®
is a registered
trademark of Dupont
™
.
Coming
Soon!
T30U models with temperature
compensation, longer sensing
ranges, shorter dead zones and
improved linearity.
