Target Signal
Strength Indicator
Output 1
Indicator
Output 2
Indicator
Output 1
Push Button
Output 2
Push Button
Sensor Power
Indicator
U-GAGE
®
QT50U
Long-range
Ultrasonic Sensor
Enhanced long-range sensing
• Senses extended range of up to 8 m
• Features ultrasonic dead-zone of only 2.5% of the
total range—75% less than comparable products
• Available in analog or discrete dc models and in ac/dc
universal voltage models with electromechanical relay output
• Offers retrosonic sensing mode
Designed for challenging applications
• Features a completely sealed, shock-resistant
housing that is ideal for monitoring levels of
liquids as well as solids
• Uses a narrow sensing beam to detect targets at
long range within confined areas—such as a
storage tank—without interference from
the tank walls
• Available in a chemically resistant model with a
Teflon
®
coating to protect the transducer
• Provides continuous monitoring (analog model)
• Offers dual-discrete option for setting independent
near and far limits for both outputs, for applications
requiring high and low-limit sensing
Engineered for flexibility
• Offers a multitude of configurations
in the same analog or discrete unit,
using an advanced microprocessor
and 8 DIP switches (dc models only)
• Compensates for temperature, for
greatest sensing accuracy
• Reduces dead zone and detects
objects of any size, shape and
orientation (retrosonic mode)
Push-button programming
• Simplifies setup with push-button and remote
TEACH-mode programming
• Shows status during setup and operation,
using highly visible LEDs indicators
* Discrete dc model shown.
PAGE 415, 419 & 421
PAGE 372
5-Pin Euro + 5-Pin Micro
+ 5-Pin Mini
Teflon
®
is a registered trademark of Dupont
™
.
Chemically resistant models
8 m
Maximum Range
200 mm
Minimum Range
Dead
Zone
