Optional built-in DeviceNet
™
fieldbus
Two controller models allow central monitoring and
control of the operation status and diagnostics of
several light screens at once over a DeviceNet control
network. MINI-ARRAY communications are available
through DeviceNet and can use change-of-state
protocol or polled communication protocol.
Heated enclosures for severe environments
The MINI-ARRAY is available with heated enclosures
for outdoor applications such as vehicle scanning in
tollbooths and similar uses. The heated enclosures
are available in 1.2, 1.5 and 1.8 m array lengths,
in both painted aluminum and stainless steel for all
environments. Optional power supplies are available
for the heated enclosures.
A-GAGE
®
MINI-ARRAY
®
Inspection and Proling
Light Screens
A compact workhorse for inspection and profiling
The programmable A-GAGE
®
MINI-ARRAY
®
measuring
light screen system is ideal for inspection and proling
applications. Each system includes an emitter/receiver pair,
one of nine controller modules and cables. Programmable
controller modules offer a selection of measurement
modes, scanning modes and output congurations.
• Features compact emitter/receiver
footprint—just 38 square mm
• Offers choice of controllers for output in discrete
(switched), analog, serial (ASCII or binary)
or DeviceNet™
• Includes advanced configuration software
• Available in two models that have 16 discrete outputs
Ten emitter/receiver heights
• Offers 10 array lengths, from 130 mm to 1.8 m, to
fit a wide range of applications
• Available with 9.5 or 19 mm beam spacing
• Makes status monitoring easy with indicators
visible from three sides
DeviceNet
™
is a trademark of the Open DeviceNet Vendor Association, Inc.
