L-GAGE
®
Q50
Low-cost LED-based
Distance Measurement
Sensors
A low-cost alternative to laser measurement sensors
The compact, self-contained L-GAGE
®
Q50 triangula-
tion sensor combines laser-like performance with LED
safety and economy. The Q50 features analog outputs
with programmable sensing window limits, and a unique
tightly collimated emitter that enables it to operate in tight
spaces or on small targets. The Q50 is an appealing laser
alternative for many applications, including dry-bulk level
measurement, package lling, roll-diameter measurement,
loop control and dimensional measurement.
Patented scalable analog output
• Automatically scales the analog output over the
width of the programmed sensing window
• Streamlines setup and maximizes resolution in
electrically noisy environments
• Offers 4 to 20 mA (current sourcing) or 0 to 10V
(voltage sourcing) output configurations
• Available with discrete output
Reliable sensing for varied targets
• 50 to 300 mm range visible red beam models
• 50 to 400 mm range infrared beam models
• Sensor linearity less than 1 percent of full scale
PAGE 416
5-Pin Euro
Programmable features
• Offers TEACH programming and remote programming
• Requires no potentiometer adjustments
• Offers choice of positive or negative analog output slope
• Allows choice of output response speed from
4 to 64 milliseconds
• Provides remote location programming for maximum
security and convenience
PAGE 372
