T30U Specifications
Sensing Performance
(Specied using a 100 x
100 mm aluminum target at
25˚ C under xed sensing
conditions.)
Analog sensing resolution or discrete output repeatability: ±0.25% of measured distance
“A” suffix models: .5 mm min
“B” suffix models: 1 mm min
Analog linearity: ±0.5% of full-scale span
Min. window size: 10 mm
Hysteresis of discrete output: 2.5 mm
Temperature effect: 0.2% of sensing distance per ° C
Adjustments
Sensing window limits (analog or discrete): TEACH-mode programming of near and far window
limits may be set using membrane push buttons on sensor or remotely using TEACH input. Window
limits may be programmed separately, or together.
Analog output slope: the rst limit taught is assigned to the minimum output value (4 mA or 0V).
Indicators
Four status LEDs: In RUN mode:
Green ON Steady: Power ON, RUN mode
Green Flashing: Discrete output is overloaded
Red Flashing: Relative received signal strength
Yellow analog ON Steady: Target is inside window limits
Yellow discrete ON Steady: Output conducting
In Program mode:
Green OFF: PROGRAM mode
Red Flashing: Relative received signal strength
Yellow ON Steady: Ready for rst window limit
Yellow Flashing: Ready for second limit
Yellow OFF: Not teaching this output
Construction
Molded reinforced thermoplastic polyester housing.
Environmental Rating
Leakproof design is rated IEC IP67; NEMA 6P
Connections
2 m or 9 m 5-conductor PVC-covered attached cable, or 5-pin Euro-style quick-disconnect tting.
QD cables are ordered separately. See page 415.
Operating Conditions
Temperature: -20° to +70° C Relative humidity: 100%
Vibration and
Mechanical Shock
All models meet Mil. Std. 202F requirements. Method 201A (Vibration: 10 to 60Hz max., double
amplitude 0.06", maximum acceleration 10G). Also meets IEC 947-5-2 requirements: 30G, 11
milliseconds duration, half sine wave.
Application Notes
Objects passing inside the specied near limit will produce a false response.
NOTE: For more information about out-of-range and signal loss response of the analog output,
see product literature.
Certifications
Hookup Diagrams
Analog/Discrete Models: MI16 (p. 535)
Dual-Discrete Models: MI15 (p. 535)
(cont’d)
