MEASUREMENT & INSPECTION
MEASURING LIGHT
SCREENS
TEMPERATURE
LIGHT
GAUGING
RADAR
ULTRASONIC
U-GAGE
®
Q45UR Analog Output, 15-24V dc
Kit Models
Kit Includes
Controller Model
Kit Includes
Sensor Model
Sensor
Range
Controller
Cable*
Controller
Output
Data
Sheet
Q45UR3LIU64CK Q45UR3LIU64C
M18C2.0
Stainless
Steel Barrel
50 - 250 mm
2 m
Selectable
0 to 10V dc
or
4 to 20 mA
59323
Q45UR3LIU64CQK Q45UR3LIU64CQ
5-pin Mini QD
Q45UR3LIU64CQ6K Q45UR3LIU64CQ6
5-pin Euro QD
Q45UR3LIU64CKQ Q45UR3LIU64C
Q13C2.0
Flat-Pak
50 - 250 mm
2 m
Q45UR3LIU64CQKQ Q45UR3LIU64CQ
5-pin Mini QD
Q45UR3LIU64CQ6KQ Q45UR3LIU64CQ6
5-pin Euro QD
Q45UR3LIU64CKS Q45UR3LIU64C
S18C2.0
Molded
Barrel
50 - 250 mm
2 m
Q45UR3LIU64CQKS Q45UR3LIU64CQ
5-pin Mini QD
Q45UR3LIU64CQ6KS Q45UR3LIU64CQ6
5-pin Euro QD
* For 9 m cable, add suffix W/30 to 2 m model number (example, Q45UR3BA63CK W/30). A model with a QD requires a mating cable (see pages 415 and 421).
U-GAGE
®
Q45UR Sensors
5-segment target position indicator
2 m or 9 m attached cable, or Mini- or
Euro-style quick-disconnect
Stainless steel barrel or plastic
threaded barrel, and Flat-Pak
transducer available
Simple push button for programming
limits of sensing window
Remote sensing heads with built in
temperature compensation
5-pin Mini- or Euro-style QD cables
with shield ordered separately
(see pages 415 and 421)
U-GAGE
®
Q45UR Discrete Output, 12-24V dc
Kit Models
Kit Includes
Controller Model
Kit Includes
Sensor Model
Sensor
Range
Controller
Cable*
Controller
Output
Data
Sheet
Q45UR3BA63CK Q45UR3BA63C
M18C2.0
Stainless
Steel Barrel
50 - 250 mm
2 m
Bipolar
NPN/PNP
59321
Q45UR3BA63CQK Q45UR3BA63CQ
5-pin Mini QD
Q45UR3BA63CQ6K Q45UR3BA63CQ6
5-pin Euro QD
Q45UR3BA63CKQ Q45UR3BA63C
Q13C2.0
Flat-Pak
50 - 250 mm
2 m
Bipolar
NPN/PNP
59321
Q45UR3BA63CQKQ Q45UR3BA63CQ
5-pin Mini QD
Q45UR3BA63CQ6KQ Q45UR3BA63CQ6
5-pin Euro QD
Q45UR3BA63CKS Q45UR3BA63C
S18C2.0
Molded
Barrel
50 - 250 mm
2 m
Bipolar
NPN/PNP
59321
Q45UR3BA63CQKS Q45UR3BA63CQ
5-pin Mini QD
Q45UR3BA63CQ6KS Q45UR3BA63CQ6
5-pin Euro QD
M18C2.0 & S18C2.0
Remote Sensors
Q13C2.0 Remote Sensors
Q45UR Controllers
(S18C2.0 Remote Sensor separate)
60.5 mm
87.6 mm
44.5 mm
