High-Resolution MINI-ARRAY
®
Controller Specifications
Analog Outputs
Voltage-sourcing outputs: 0 to 10V dc (25 mA current limit)
Current-sinking outputs: 4 to 20 mA (16 to 30V dc input)
Resolution: Span / Number of sensing channels
Linearity: 0.1% of full scale Temperature variation: 0.01% of full scale per ° C
Output Configuration
MAHCVP-1: Two PNP discrete (switched), two 0-10V voltage sourcing
MAHCVN-1: Two NPN discrete (switched), two 0-10V voltage sourcing
MAHCIP-1: Two PNP discrete (switched), two 4-20 mA current sinking
MAHCIN-1: Two NPN discrete (switched), two 4-20 mA current sinking
System Programming
Via RS-232 interface to PC-compatible computer running Windows
®
95, 98, NT, ME, XP or 2000 and
using software supplied with each control module.
Status Indicators
Output 1(Red): Lights to indicate Discrete Output #1 is active
Alarm (Red): Lights to indicate Discrete Output #2 is active
Gate (Red): Lights to indicate Trigger (Gate) is active
Align (Green): Lights to indicate emitter and receiver are aligned
Diagnostics indicator: (Key on controller side label) Identifies System errors and status
Construction
Polycarbonate housing; mounts to flat surface or directly onto 35-mm DIN rail
Environmental Rating
NEMA 1; IP20
Operating Conditions
Temperature: 0° to +50° C Relative humidity: 95% @ 50˚ C (non-condensing)
Certifications
Hookup Diagrams
0-10V sourcing: MI25 (p. 538) 4 to 20 mA voltage: MI26 (p. 538)
A-GAGE
®
High-Resolution MINI-ARRAY
®
Sensor Specifications
Emitter/Receiver Range
380 mm to 1.8 m
Minimum Object Sensitivity
2.5 mm
Sensor Scan Time
1.8 to 58.4 milliseconds, depending on scanning method and sensor length plus 1 millisecond post
processing time for controller.
Power Requirements
12V dc ±2%, supplied by controller
Connections
Sensors connect to controller using two 5-conductor quick-disconnect cables (one each for emitter
and receiver), ordered separately. Use only Banner cables, which incorporate a “twisted pair”
for noise immunity. Cables measure 8.1 mm in diameter and are shielded and PVC-jacketed.
Conductors are 20 gauge (0.9 mm). Emitter and receiver cables may not exceed 75 m long, each.
See page 421.
Status Indicators
Emitter: Red LED lights to indicate proper emitter operation
Receiver: Green indicates sensors aligned
Yellow indicates marginal alignment of one or more beams
Red indicates sensors misaligned or one or more beam(s) blocked
Construction
Aluminum, with black anodized finish; acrylic lens cover
Environmental Rating
NEMA 4, 13; IP65
Operating Conditions
Temperature: 0° to +50° C Relative humidity: 95% at 50° C (non-condensing)
Certifications
A-GAGE
®
High-Resolution MINI-ARRAY
®
Controller Specifications (cont’d)
