Controller Specifications
Construction
Polycarbonate
Environmental Rating
NEMA 1; IP20
Operating Conditions
Temperature: -20° to +70° C Relative humidity: 95% (non-condensing)
Certifications
Hookup Diagram
MAC-1: MI27 (p. 538) MACN-1/MACP-1: MI28 (p. 538)
MACV-1/MACI-1: MI29 (p. 539) MAC16N-1/MAC16P-1: MI31 (p. 539)
A-GAGE
®
MINI-ARRAY
®
Controller with DeviceNet
™
Specifications
DeviceNet Configurations
Vendor code: 12 (Banner Corp.)
Device type: 110
Product code: 1 (MACNXDN-1)
2 (MACPXDN-1)
Connection types supported: Explicit Message, Poll, COS
Network address: 0-63 (network congured), default = 63
Baud rate supported: 125K, 250K, 500K (network congured), default = 125K
Output Configurations
MACPXDN-1: Two PNP discrete (switched)
MACNXDN-1: Two NPN discrete (switched)
Power Requirements*
Controller, emitter and receiver: 16 to 30V dc @ 1.2 A max. (typical: 0.5 A @ 16V dc)
DeviceNet Power*
11 to 25V dc - supplied by DeviceNet BUS Network
Inputs
Sensor input: Emitter and receiver wire in parallel to ve terminals.
Trigger (Gate) input: Optically isolated, requires 10 to 30V dc (7.5 kΩ impedance) for gate signal
Discrete Outputs
NPN outputs: Open collector NPN transistor rated at 30V dc max., 150 mA max.
PNP outputs: Open collector PNP transistor rated at 30V dc max., 150 mA max.
All discrete outputs: OFF-state leakage current: less than 10 µA @ 30V dc
ON-state saturation voltage: less than 1V @ 10 mA; less than 1.5V @ 150 mA
System Programming
Via DeviceNet interface and supplied EDS les.
System Status Indicators
Output (steady red): Output #1 energized.
Alarm (flashing red): Output #2 energized.
Gate (steady red): Trigger (Gate) input status.
Alignment (steady green): Proper emitter/receiver alignment and a clear, unblocked light screen
(ON) when green or green/yellow receiver LEDs are ON.
Diag 1 (Green), Diag 2 (Red), Diag 3 (Red): Used in combination to display System status
Network Status Indicator
Bicolored (Red/Green) LED visible on the control module front panel indicates network status:
Steady Green: On-line, connected to master
Flashing Green: On-line, address and baud rate OK
Steady Red: Critical network fault or duplicate node address detected
Flashing Red: Connection timeout
OFF: No network power or off-line
Construction
Polycarbonate housing; mounts to at surface or directly onto 35-mm DIN rail
Environmental Rating
NEMA 1; IP20
Operating Conditions
Temperature: -20° to +70° C Relative humidity: 95% @ 50° C (non-condensing)
*Application Note
The controller must be powered up before the DeviceNet connection in every power-up situation for
proper operation
Hookup Diagrams
MI30 (p. 539)
DeviceNet
™
is a trademark of the Open DeviceNet Vendor Association, Inc.
(cont’d)
