TASCAM DP-32SD 29
Creating a new song
Follow these procedures to create a new song.
1. When the recorder is stopped, press the MENU button to
open the
MENU
screen.
2. Use the JOG/DATA dial or the CURSOR (5/b/g/t)
buttons to select (highlight green)
SONG
, and then press the
F4 (t) button.
The
SONG LIST
screen opens.
3. Press the F4 (t) button to open the menu.
Use the JOG/DATA dial or the CURSOR (5/b) buttons to
select
CREATE
from the menu, and then press the F4 (t)
button.
4. Press the F4 (t) button to open the
SONG CREATE
pop-
up window.
The created song will automatically be given a name
according to the
Song Name Type
setting in the
PREFERENCE
menu.
5. Change the song name in the
Name
item if you want. (See
“Editing names” on page 28.)
TIP
You can edit the name of a song later by selecting
NAME EDIT
from the
SONG
screen. You can also edit the song name when
saving the song.
6. Align the cursor with
Bit
and turn the JOG/DATA dial to set
the bit rate. (Default: 16bit)
7. Align the cursor with
Hz
and turn the JOG/DATA dial to set
the sampling frequency. (Default: 44.1kHz)
8. Press the F2 (
YES
) button to save the currently loaded song
and create a new song.
NOTE
If you press the F1 (
NO
) button, the pop-up window disappears
from the
SONG LIST
screen.
9. Once the song is created, the pop-up window disappears
from the
SONG LIST
screen.
10. Press the HOME button to return to the Home screen.
5 - Song Management
Saving a song
This unit automatically saves the current song during shutdown
and when loading another song. You can also save a song at any
time using the following procedure.
1. When the recorder is stopped, press the MENU button to
open the
MENU
screen.
2. Use the JOG/DATA dial or the CURSOR (5/b/g/t)
buttons to select (highlight green)
SONG
, and then press the
F4 (t) button.
The
SONG LIST
screen opens.
3. Press the F4 (t) button to open the menu.
Use the JOG/DATA dial or the CURSOR (5/b) buttons
to select
SAVE
from the menu, and then press the F4 (t)
button.
4. Press the F4 (t) button to open the
SONG SAVE
pop-up
window.
5. Change the song name in the
SongName
item if you want.
(See “Editing names” on page 28.)
To save without changing the name, just press the F2 (
YES
)
button.
6. Once the song is saved, the pop-up window disappears from
the
SONG LIST
screen.
7. Press the HOME button to return to the Home screen.
TIP
The
SAVE
item, which is one of the
SONG LIST
menu items, can
also be selected using the F2 (
SAVE
) button on the Home screen.
