9840 Tape Drive Operations Guide—429596-002
4-18
Entering Cartridges Through the CAP
4. Press the arrow buttons until the cursor highlights EXPORT CLEANING
CARTRIDGE.
5. Press the SELECT button. The export screen appears, which lists all installed
cleaning cartridges by domain (or cartridge type), VOLSER, and usage count.
6. Press the MENU button to exit out of the export screen.
Entering Cartridges Through the CAP
To unlock the CAP, open it, and place cartridges into it:
1. Enter the console command to unlock the CAP.
2. Press the CAP A or CAP B button on the operator panel to open the CAP. The
indicator will light.
3. Load the cartridges into the magazine. This can be done in one of two ways: Pull
out and down on the magazine handle or remove the magazine by lifting it out. See
Figure 6-1.
Note. If the usage count for a cleaning cartridge has exceeded its warning count, the export
screen will display EXPIRED. The user must remove this cartridge from the library.
Caution. The cartridges must be entered properly or the robot or tape drive might be
damaged, or the tape library could stop operating. Use only 9840 cartridges for 9840 drives.
