9840 Tape Drive Operations Guide—429596-002
4-11
Display Screens
Drive Configuration
Accessible from the Main Configuration Menu, the drive configuration menu lets you
modify portions of each drive’s configuration. Figure 4-12 shows an example screen.
For each drive, the menu displays the tape drive position, drive type, SCSI ID and
indicates whether the drive is on the same SCSI bus as the library.
The panel only displays 16 lines per screen. If the library contains more than eight
drives, the user must use the down arrow button to scroll to drive 09 and above. For
more information, see “Drive Information” in Chapter 5.
Figure 4-11. Library Configuration Menu
Note. The cursor position is saved on all screens that list the library’s drives.
