9840 Tape Drive Operations Guide—429596-002
4-10
Display Screens
Configuration Menu
Accessible from the Main Menu (Figure 4-10) routes the user to the configuration
menus (library, drive, and network) and to the panel display controls.
Library Configuration
Accessible from the Main Configuration menu, the Library Config menu displays library
capacity information and lets you modify library’s configuration. Figure 4-11 shows an
example library configuration screen.
The screen lets you:
The screen lets you set the:
Figure 4-10. Configuration Menu
SCSI ID Library’s SCSI identification number
Fast Load Fast Load feature on or off
Date Current date
Time Current time
SCSI Type What type of SCSI bus connects the library to the network
(differential or single-ended)
Auto Clean Whether Auto Clean is enabled
CAPs The number of CAPs installed
User Cells How many data storage cells the library contains
Drive Column The number of drive columns installed
Expansion Frame Whether an expansion frame is installed
