56
* B = Bank, S = Sensor
(The location of Cylinder #1 designates the side of Bank 1 on the engine block.)
7.2 Appendix 2 -- In-use Performance Tracking Data List
EVAP_VP(Pa) Evap System Vapor Pressure AAT(°F) Ambient Air Temperature
BARO(Kpa) Barometric Pressure BARO(inHg) Barometric Pressure
O2S11(mA) O2 Sensor Current
(wide range O2S) B1S1*
O2S21(mA) O2 Sensor Current
(wide range O2S) B2S1*
O2S12(mA) O2 Sensor Current
(wide range O2S) B1S2*
O2S22(mA) O2 Sensor Current
(wide range O2S) B2S2*
CATEMP11(°F) Catalyst Temperature B1S1* CATEMP12(°F) Catalyst Temperature B1S2*
CATEMP21(°F) Catalyst Temperature B2S1* CATEMP22(°F) Catalyst Temperature B2S2*
TP (%) Absolute Throttle Position TAC_PCT (%) Commanded Throttle Actuator Con-
trol
TP_R (%) Relative Throttle Position APP_D (%) Accelerator Pedal Position D
TP_B (%) Absolute Throttle Position B APP_E (%) Accelerator Pedal Position E
TP_C (%) Absolute Throttle Position C APP_F (%) Accelerator Pedal Position F
Abbreviation Full Name Definitions
OBDCOND OBD Monitoring
Conditions
Encountered Counts
OBD Monitoring Conditions Encountered Counts
displays number of times that the vehicle has been
operated in the specified OBD monitoring conditions
(general denominator).
IGNCNTR Ignition Counter
Ignition Counter displays the count of number of times
that the engine has been started.
CATCOMP1 Catalyst Monitor
Completion Counts
Bank 1
Catalyst Monitor Completion Counts Bank 1 displays
number of times that all conditions necessary to
detect a catalyst system bank 1 malfunction have
been encountered (numerator).
CATCOND1 Catalyst Monitor
Conditions
Encountered Counts
Bank 1
Catalyst Monitor Conditions Encountered Counts
Bank 1 displays number of times that the vehicle has
been operated in the specified catalyst monitoring
conditions (denominator).
CATCOMP2 Catalyst Monitor
Completion Counts
Bank 2
Catalyst Monitor Completion Counts Bank 2 displays
number of time that all conditions necessary to detect
a catalyst system bank 2 malfunction have been
encountered (numerator).
CATCOND2 Catalyst Monitor
Conditions
Encountered Counts
Bank 2
Catalyst Monitor Conditions Encountered Counts
Bank 2 displays number of times that the vehicle has
been operated in the specified catalyst monitoring
conditions (denominator).
O2SCOMP1 O2 Sensor Monitor
Completion Counts
Bank 1
O2 Sensor Monitor Completion Counts Bank 1
displays number of time that all conditions necessary
to detect an oxygen sensor bank 1 malfunction have
been encountered (numerator).
