25
• If no data is stored in the scan tool, above prompt will not show up.
8) If you wish to erase the data, press 'ENTER'; if you do not want to erase the
data, press ESC or use the LEFT/RIGHT button to select NO and press ENTER to
return to the Diagnostic Menu.
5.1 System Status
Press ENTER to select System Status, the following screen will be
displayed if there is only one control module. Press SCROLL to exit
System Status and return to the main Diagnostic Menu.
System Status Screen
This screen displays the current (live) conditions of each of the eleven
emissions monitors (see pg. 45). These monitors are continuously
updated. Monitors N/A are those “not available” on the current vehicle.
Monitors OK have completed their tests. Monitors INC have yet to be run
(tested). Since this is a live screen which continuously updates, the vehicle
can be driven until the monitors INC (incomplete monitors) graph is empty
of solid blocks. Additionally, while monitoring this screen, an audible
beep will be heard upon completion of each incomplete monitor. If no
beep is heard, see “3.8 Product Setup” on page 14 to turn ‘beep set’ on.
For more precise information on which monitors have been tested or not,
see 5.6 Retrieving I/M Readiness Status on page 43.
Diagnostic Menu
1/12
System Status
Read Codes
Erase Codes
Live Data ?
View Freeze Frame
I/M Readiness
System Status
MIL Status OFF
Codes Found 0
Monitors N/A 3
Monitors OK 5
Monitors INC
