54
6. Print Data
The Print Data function allows printing out diagnostic data recorded by the
scan tool or customized test reports.
To print out retrieved data, you need the following tools:
AutoLink AL510
Pro
TM
Scan Tool
A PC or laptop with USB ports
The USB cable supplied with product
1)Place included CD into CD-Drive and download the installation software. For
the latest version of software visit our website: www.autel.us
.
2)Follow on screen instructions on your computer to install the updates.
3)Launch “AutoLink
Pro
Software”, and start the printing application by selecting
Scan Tool > AL510 > Print.
4)Connect the scanner to computer with the USB cable supplied.
5)Use the UP/DOWN scroll button to select Print Data from Main Menu, and
press ENTER.
6)Use the UP/DOWN scroll button to select the desired item to print from the
Print Data menu.
Main Menu
4/6
Diagnostics
DTC Lookup
Review Data ?
? Print Data
System Setup
Tool Information
Main Menu
Print Data
1/9
? Stored Codes
Pending Codes
Live Data ?
Freeze Frame
I/M Readiness
O2 Sensor Test
Print Data
