Recording Data
The Record Data function allows recording of the vehicle modules’
Parameter Identification Data (PID) to help diagnose intermittent vehicle
problems. A recording includes five (5) frames of live data before the
trigger event and several frames after the trigger event.
There are two trigger modes used to record data:
A. Manual Trigger - allows user to press ENTER to start recording.
B. DTC Trigger - automatically records PID data when a fault that causes a
DTC to set is detected by the vehicle.
CAUTION: DO NOT try to drive and operate the scan tool at the same time!
Always have another person operate the scan tool while driving.
1)To record live data, use the UP/DOWN scroll button to select Record Data from
Live Data menu and press ENTER.
Recording Complete Data Set
2)To record a complete set of live data, use the UP/DOWN scroll button to select
Complete Data Set from Record Data menu and press ENTER.
3)Use the UP/DOWN scroll button to select a trigger mode and press ENTER.
……………….Live Data…………………….
2/3
View Data
? Record Data
Playback Data ?
………………..Record Data……… ……..
? Complete Data Set
Custom Data Set
Unit of Measure ?
