For CAN-equipped vehicles, test results can be as shown below:
6)Press ESC to return to the previous menus.
5.9 Component Test
The Component Test function allows initiating a leak test for the vehicle's
EVAP system. The scan tool itself does not perform the leak test, but
commands the vehicle's on-board computer to start the test. Different
vehicle manufacturers might have different criteria and methods for
stopping the test once it has been started. Before starting the Component
Test, refer to the vehicle service manual for instructions to stop the test.
1)Use the UP/DOWN scroll button to select Component Test from Diagnostic
Menu and press ENTER.
2)Wait a few seconds while the scan tool validates the PID MAP.
O2 Mon. B1S1
Rich-Lean Threshd. (MV)
MEAS: 0.450
MIN: 0.312
MAX: 0.630
STS: OK
O2 Mon. B1S1
Diagnostic Menu
9/1
2
O2 Monitor Test
On-Board Mon. Test
Component Test
Vehicle Info. ?
Modules Present
Unit of Measure
Diagnostic Menu
Component Test
Reading PID…
- Please Wait -
Component Test
