• The number “5/60” in the upper right corner of the screen indicates the
maximum frames that can be recorded and the number of recorded
frames.
7)The scan tool keeps recording PID data until user presses ESC, selected
memory location is full, or it completes recording. A message prompting to
playback data shows on the screen.
• If you wish to playback recorded data, press 'ENTER'; if you do not wish
to playback, press ESC, or use the LEFT/RIGHT button to select NO and
press ENTER to return to Record Data menu.
Recording 5/60
6
DTC_CNT 6
FUELSYS1 OL
FUELSYS2 N/A
LOAD_PCT(%) 0.0
ETC(℃) -40
? SHRTFT1(%) 0.0
Record Data
Record Done!
Playback data?
YES NO
Record Data
Record Data
1/
3
? Complete Data Set
Custom Data Set
Unit of Measure ?
Record Data
