• If Manual Trigger is selected, the following screen shows:
• If DTC Trigger is selected, the following screen shows:
14)Wait for DTC to trigger recording or press ENTER to start recording.
15)The scan tool keeps recording PID data until user presses ESC button, the
selected memory location is full, or it completes recording. A message
prompting to playback data shows on the screen.
Manual Trigger.
Ready to record!
Press [ENTER] to
start recording.
Press [ESC] to exit
Manual Trigger
DTC Trigger
Waiting for DTC to
trigger recording…
Press [ESC] to exit
DTC Trigger
Recording 5/60
6
DTC_CNT 6
FUELSYS1 OL
FUELSYS2 N/A
LOAD_PCT(%) 0.0
ETC(℃) -40
? SHRTFT1(%) 0.0
Record Data
Record Done!
Playback data?
YES NO
Record Data
