31
The number “6” to the right of the screen indicates the sequence of the
highlighted item.
If you want to view the full name of the highlighted PID, press the Help
button.
If the “G” icon appears when a PID is highlighted, graphic information is
available. Press ENTER to view.
6)Press ESC to return to previous menu.
Viewing Custom Data Set
7)To view customized PID data, use the UP/DOWN scroll button to select
Custom Data Set from the View Data menu and press ENTER.
8)Observe on-screen instructions.
9)Use RIGHT button to deselect/select data parameters, and use the UP/DOWN
scroll button to move up and down. Selected parameters are marked with
solid squares.
RPM (/min) 975
1725
925
……………….View Data……………… ….
2/3
Complete Data Set
? Custom Data Set
Unit of Measure ?
……………Custom Data Set……… …..
[ ] – Select/Deselect
[
] – Deselect all
[ENTER] – Confirm
[ESC] - Cancel
