D-Link ShareCenter Pulse User Manual
Page 7
These lights will be solid BLUE when drives are connected but inactive. The lights will blink when the drives are being
accessed, formatted or synchronized. They will illuminate AMBER if a drive has failed.
This light will illuminate when a USB device is inserted into the USB Port. When there’s traffic this light will blink.
This is the USB Port. Devices like a USB Print Server, UPS or USB drive can be inserted here.
This light will illuminate when this ShareCenter Pulse is powered on.
Press this button once to power on the ShareCenter Pulse. Press and hold the button until it begins to blink to power down the
ShareCenter Pulse.
Press this button to copy data from USB drive to ShareCenter Pulse. Press and hold 5 seconds to un-mount USB drive.
This latch can open and close by simply pressing it.
USB Copy Button
Power Button
Power Light
HDD1 Light
USB Light
HDD2 Light
