28 DXZ945MP
English
Multi-session selection
This function allows you to select either CD-DA
or MP3/WMA files in the case of discs (e.g. CD-
EXTRA) containing a mixture of CD-DA (music
CD) and MP3/WMA files.
1. Touch MODE.
2. Touch M-SESS.
Each touch of M-SESS toggles the M-SESS
display between “CD” (play CD-DA) or
“MP3/WMA” (play MP3/WMA).
∗ If M-SESS is not displayed, touch NEXT.
3. Touch RTN.
The multi-session selection setting is
reflected the next time you load a CD.
Note:
• When playing a CCCD (Copy Control CD), set the
setting to CD type. When this is set to MP3/WMA
type, the cannot be playing normally in some
cases.
Disc-In-Play function
As long as the ignition key is turned to the ON
or ACC position, the control panel opens by
pressing the [Q] button even if this unit is not
turned on. This function also allows you to turn
the unit on and start playing the disc
automatically.
CAUTION
Be careful not to catch your hand or fingers
while closing the SLOPING CONSOLE.
Notes:
• If the SLOPING CONSOLE does not open fully,
gently open with your hand.
• After loading a CD, always close the SLOPING
CONSOLE.
• Do not try to put your hand or fingers in the
CD SLOT. Also never insert
foreign objects into the slot.
• Do not load discs where adhesive comes out
from cellophane tape or a rental CD label, or
discs with marks where cellophane tape or
rental CD labels were removed. It may be
impossible to eject these discs from the unit
and they may cause the unit to break down.
CD / MP3 / WMA Operations
Loading a CD
1. Press the [Q] button.
The control panel opens.
2. Load the disc into the CD SLOT.
When the disc is loaded, the control panel
automatically closes after several seconds,
and play starts.
Notes:
•Never insert foreign objects into the CD SLOT.
• If the CD is not loaded easily, there may be
another CD in the mechanism or the unit may
require service.
• Discs not bearing the or mark and
CD-ROMs cannot be played by this unit.
• Some CDs recorded in the CD-R/CD-RW mode
may not be usable.
Loading 8 cm compact discs
No adapter is required to play an 8 cm CD.
Load the 8 cm CD into the center of the CD
SLOT.
Ejecting a CD
You can eject a disc by pressing the [Q] button
even if the engine key or ACC is at the OFF
position automatically.
CAUTION
When the disc is ejected, press the [Q]
button to close the control panel. If the
control panel is left open, You will hear a
double beep, and the control panel
automatically closes.
1. Press the [Q] button.
The control panel opens, and the disc is
ejected. The mode automatically switches to
the radio mode.
∗ Be sure to remove ejected discs from this
unit. If you leave the disc in the disc tray, it
is pulled back into the unit after 15
seconds or longer, and the control panel
closes. (auto reload function)
∗ Single CDs are not auto-loaded. Be sure
to remove single CDs after ejecting them.
CAUTION
If you use excessive force to load a disc
after it has been ejected, the surface of the
disc may become scratched. Remove the
disc before loading it again
