20 DXZ945MP
English
CAR LENGTH:
Adjusts the deviation in sound pressure along
the length of the car.
1. Press the [SOUND] button.
2. Touch VSE.
3. Touch on the ON/OFF display.
The VSE effect is toggled ON/OFF.
4. Touch B/U to select “BASIC” or “USER”.
5. Touch on the right of the display to
select the menu that is used as the menu for
adjustment.
6. Press the [A] button.
7. Touch on the adjustment item display
to select “DIFFUSE”, “CAR WIDTH” or “CAR
LENGTH”.
RTN
VSE EDIT
DIFFUSE
5
8. Touch on the right of the display and
adjust the item as desired.
∗ This item can be adjusted within the range
1 to 10.
9. Repeat steps 7 and 8 to adjust the desired
item.
10.When you have finished adjusting each item,
touch RTN.
The display returns to the original screen,
and “” is displayed at the BASIC or USER
display.
Operation so far completes VSE adjustment.
To continue to store the adjustment values to
the VSE user menu, perform the following.
11.Touch and hold RTN for 1 second or longer.
The VSE user menu list is displayed.
12.Touch and hold the user memory you want
to store the adjustment values to for 2
seconds or longer.
You will hear a long beep, and the values
you adjusted up to step 9 are stored to the
VSE user menu.
If you hear a short beep, the adjustment
values up to step 9 are discarded. Adjust
these values again as required.
13.Touch RTN.
14.Press the [SOUND] button to return to the
original mode.
∗ To select a stored user memory, touch B/U
to display “USER” and touch on the
user memory No.
AC-Processor III Operations
Selecting the P.EQ menu
P.EQ (Parametric Equalizer) allows you to
compensate the entire frequency level range in
detail by smooth curve using frequency
compensation matched to the type of your car.
In the “Selecting each mode” procedure (cf.
page 39), set EQ SELECT to “P.EQ”.
• The factory default setting for P.EQ is “OFF”
and for the P.EQ basic menu is “SEDAN-1”.
■ P.EQ basic menu
6 types of P.EQ basic menu are pre-stored to
this function matched to the type of your car and
the speaker mounting position. Select the basic
menu to suit you car.
1. Press the [SOUND] button.
2. Touch P.EQ.
RTN
2 - ZONE
POSITION
OFF
OFF
ADF
P. EQ
OFF
OFF
A - MODE
Dolby PL
II
OFF
SOUND MENU
3. Touch on the ON/OFF display.
The P.EQ effect is toggled ON/OFF.
BASIC
B/U
BU
RTN
1
26
OFF
SEDAN-1
P.EQ MODE
When the P.EQ effect is set to “OFF”, the
P.EQ setting is not reflected on the music
source. This ends the P.EQ setting. Press
the [SOUND] button to return to the original
mode.
4. Touch B/U to select “BASIC”.
BASIC
B/U
BU
RTN
1
26
ON
SEDAN-1
P.EQ MODE
Each touch of B/U toggles between “BASIC”
and “USER”.
5. Touch on the P.EQ basic menu No. to
select the P.EQ basic menu.
