Lowrance - LHR-80 Installation and Operation Instructions
37
4-6-8 Turn GPS ENABLE on/off
SETTING
COG/SOG
GPS ALERT
>GPS ENABLED
GPS ENABLED
>ON
OFF
In radio set-up menu, select GPS/DATA then SETTING, next GPS ENABLED.1.
Select ON/OFF as desired, in this example, ON has been selected, so the GPS ENABLED 2.
is turned ON.
4-6-9 Set True or Magnetic Bearing
SETTING
GPS ALERT
GPS ENABLED
>BEARING
BEARING
>TRUE
MAGNETIC
In radio set-up menu, select GPS/DATA then SETTING, next BEARING. 1.
Select TRUE/MAG VAR as desired, then press ENTER to confirm.2.
Note: True is the default.
If MAG VAR is selected. Then use CH / to adjust the MAGNETIC difference between true
and variation, then press ENTER to confirm selection.
MAG VARIATION
XX.X
°W (or E)
Note: W is the default and tenths of a degree is required.
SAVE
>YES
NO
