Lowrance - LHR-80 Installation and Operation Instructions12
The channel is used mostly for weather. Press again to return to your previous mode. Hold
down WX/NAV for more than 3 seconds to enter Navigation mode Bearing, Distance and
cross track error from the last select Way Point will display on the screen. If no WP is set, it will
appear “NO ACTIVE ROUTE!!” prompt.
NAV. Press NAV to enter Navigation mode Bearing. Distance and cross track error from the
Waypoint will display on screen. If no WP is set, it will appear “NO ACTIVE ROUTE!!” prompt.
GO/MOB
Press GO / MOB if you are navigating to waypoint and want to reset the XTE (cross track error)
as shown on the screen.
If someone falls overboard, holds down GO / MOB for about 3 seconds to mark the position.
The latitude and longitude of the Man Overboard position is shown on the screen and is
automatically set as the destination waypoint.
PTT
Push To Talk. Push to start the transmitting
CALL/MENU
Quickly press the CALL/MENU key to access the DSC Call menu. The call mode is used for
making DSC calls. Hold down the Key more than 3 seconds to access the Menu Setup mode
and to customize your VHF radio. US only
MENU. Quickly press the MENU key to access the Menu setup mode and to customize your
VHF radio (EU only).
Please refer to the following sections for more details.
CAUTION
BATTERY CAUTION: This device uses a Lithion Ion battery - please observe the following
cautions.
Do not disassemble.•
Do not incinerate or expose to fire.•
Dispose of used batteries according to local codes and requirements.•
