Lowrance - LHR-80 Installation and Operation Instructions 21
3-11 Scan Operation
Scanning is an effective way to locate signals quickly over a wide frequency ranger.
All Scan
All channels in the set are scanned sequentially, in repeated cycles (CH16 is checked every 1.5
seconds).
01
02
03
16
04
88
3CH Scan
Press and hold down the SCAN key in the 3CH mode, you will then enter a 3CH SCAN mode.
However, only the 3CH and CH16 will be scanned.
01
15
18
16
01
18
3-12 Navigation Mode
Press and hold down NAV key, (US only), or just press the NAV key (EU only) to enter the
Navigation Mode. It will display: Bearing, Distance and cross track error from the last selected
waypoint.
If no WP is set, ‘NO ACTIVE ROUTE!!’ will appear to prompt you that no WP is selected.
During Nav Mode:
PTT – return to normal mode and TX.•
16/9 – return to normal mode and go to 16/9•
