Lowrance - LHR-80 Installation and Op 13
Section 3 - VHF Radio Operation
3-1 Batteries and Charger
The radio is shipped with a sealed Li-Polymer battery pack that is rechargeable.
WARNING
The charger provided for this radio is only to be used to charge the battery pack provided.
DO NOT charge any other type of batteries in the charger as fire, explosion or battery
damage will occur. Avoiding extreme room temperature will also help prolong the life of
the battery pack for the radio.
3-1-1 Installing the Battery Pack
Position the battery pack to line up the three external alignment tabs to the alignment 1.
slots in the radio.
Engage the battery pack into the radio until battery pack is fully seated against the radio
2.
housing.
Pivot the locking tab up until it snaps into place on the back of the battery pack.
3.
3-1-2 Initial Charge
You can either charge the Li-Polymer battery
pack when it is attached to the radio or separated:
